How We Rebuilt Our ML Infrastructure to Handle 100M+ Daily Predictions

4 min readNov 7, 2024

ML Architecture Evolution: From Microservices to Scalable ML Systems

Introduction

When our team started building our product recommendation engine, we followed the standard advice: “Use microservices for flexibility and scalability.” Six months and $45K in technical debt later, we learned that conventional wisdom doesn’t always apply to ML systems.

This article details our journey from a simple microservice architecture to a robust ML system handling 100M+ daily predictions. More importantly, it explains why common software architecture patterns might not be the best fit for ML systems.

The Initial Architecture

Our first architecture was what you’d expect from any modern application:

# Initial FastAPI service
from fastapi import FastAPI
from transformers import RecommenderModel

app = FastAPI()
model = RecommenderModel()

@app.post("/predict")
async def get_recommendations(user_id: str):
    user_features = await get_user_features(user_id)
    recommendations = model.predict(user_features)
    return {"recommendations": recommendations}

Simple, clean, and followed all the microservice best practices. But it had several hidden problems:

Cold Starts: Every new instance loaded the model from scratch
Resource Utilization: Idle instances still consumed full memory
Data Freshness: Features were often stale
Scaling Issues: Linear resource scaling with request volume

The Evolution

1. Request Handling Layer

The first major change was splitting read and write paths:

# Separated read/write paths with batching
from typing import List
from fastapi import FastAPI, BackgroundTasks
from pydantic import BaseModel

app = FastAPI()
batch_processor = BatchProcessor()

class PredictionRequest(BaseModel):
    user_id: str
    context: dict

@app.post("/predict/batch")
async def batch_predictions(requests: List[PredictionRequest]):
    # Handle batch of requests
    batch_id = batch_processor.queue_batch(requests)
    return {"batch_id": batch_id}

@app.get("/predict/{batch_id}")
async def get_batch_results(batch_id: str):
    # Retrieve batch results
    results = batch_processor.get_results(batch_id)
    return results

@app.post("/predict/realtime")
async def realtime_predict(request: PredictionRequest):
    # Priority queue for realtime requests
    if is_priority_user(request.user_id):
        return await realtime_processor.predict(request)
    return await batch_processor.quick_predict(request)

Key improvements:

Batch processing for efficiency
Priority queuing for important requests
Circuit breakers for system protection

2. Prediction Layer

The biggest performance gain came from intelligent caching:

# Intelligent caching layer
from functools import lru_cache
from redis import Redis
from typing import List, Dict

class PredictionCache:
    def __init__(self):
        self.redis = Redis()
        self.local_cache = {}

    @lru_cache(maxsize=10000)
    def get_cached_prediction(self, user_id: str, context: Dict):
        # Try local cache
        cache_key = f"{user_id}:{hash(str(context))}"
        if cache_key in self.local_cache:
            return self.local_cache[cache_key]

        # Try Redis cache
        cached = self.redis.get(cache_key)
        if cached:
            self.local_cache[cache_key] = cached
            return cached

        # Generate new prediction
        prediction = self.generate_prediction(user_id, context)

        # Cache with appropriate TTL
        ttl = self.calculate_ttl(user_id, context)
        self.redis.setex(cache_key, ttl, prediction)
        self.local_cache[cache_key] = prediction

        return prediction

    def calculate_ttl(self, user_id: str, context: Dict) -> int:
        # Dynamic TTL based on user behavior and context
        base_ttl = 3600  # 1 hour
        if is_active_user(user_id):
            base_ttl = 1800  # 30 minutes
        if is_high_volatility_context(context):
            base_ttl = 300  # 5 minutes
        return base_ttl

This caching system provided:

Multi-level caching (local + Redis)
Dynamic TTL based on user behavior
Pre-computation for popular items
Intelligent cache invalidation

3. Data Processing Layer

Event-driven processing transformed our data freshness:

# Event-driven data processing
from pydantic import BaseModel
from typing import List, Optional

class FeatureStore:
    def __init__(self):
        self.feature_validators = {}
        self.quality_gates = {}

    async def process_event(self, event: Dict):
        # Process events as they arrive
        features = self.extract_features(event)
        if self.validate_features(features):
            await self.update_features(features)
            await self.trigger_recomputation(features)

    def validate_features(self, features: Dict) -> bool:
        # Data quality gates
        for feature, value in features.items():
            if feature in self.quality_gates:
                if not self.quality_gates[feature](value):
                    log_quality_issue(feature, value)
                    return False
        return True

    async def update_features(self, features: Dict):
        # Incremental feature updates
        for feature, value in features.items():
            await self.feature_store.update(
                feature_name=feature,
                value=value,
                timestamp=datetime.now()
            )

    async def trigger_recomputation(self, features: Dict):
        # Trigger async model updates if needed
        affected_models = self.get_affected_models(features)
        for model in affected_models:
            await self.model_updater.queue_update(model)

This approach enabled:

Real-time feature updates
Data quality monitoring
Incremental model updates
Feature freshness tracking

The Counter-Intuitive Learnings

1. Fewer Services, Better Performance

Instead of having separate services for every function, we consolidated into three main components:

Request Handler
Prediction Engine
Data Processor

This reduced network hops, simplified monitoring, and improved reliability.

2. Caching > Computational Optimization

We spent weeks optimizing our model inference before realizing that intelligent caching would give us better results with less complexity.

3. Data Flow > Service Architecture

Focus on optimizing how data moves through your system rather than how code is organized into services.

Performance Metrics

Before and after comparison:

| Metric            | Before  | After   | Improvement |
|-------------------|---------|---------|-------------|
| Latency (p95)     | 2000ms  | 150ms   | 92.5%       |
| Cost per prediction | $0.001 | $0.0001 | 90%         |
| System uptime     | 99.9%   | 99.99%  | 0.09%       |
| Data freshness    | 4 hours | 5 minutes | 98%       |

Start Simple

Begin with a monolith
Identify bottlenecks through monitoring
Split only what causes problems

2. Cache Strategically

Implement multi-level caching
Use dynamic TTLs
Pre-compute popular predictions

3. Monitor Everything

Track business metrics
Monitor data quality
Set up alerting for degradation

4. Build Fallbacks

Implement degraded service modes
Have backup prediction strategies
Design for failure

Conclusion

The microservices architecture pattern, while excellent for many applications, isn’t always the best fit for ML systems. The key is to understand your specific requirements and constraints, then design accordingly.

Remember:
